The prototype is defined as an original model where something is modeled.
The prototype circuit board is the working model of the printed circuit board (PCB)
Especially created to check the functionality of the final PCB.
Prototype can be created before small and large
Requirements for mass production.
In some cases, prototyping is also done for individual PCB requirements.
Why just need a prototype like the circuit diagram of the PCB can not be used as an effective basis for the final product manufacturing, it is necessary to first convert the chart into the actual PCB and check its feasibility.
Once the feasibility is established and the improvement is analyzed, the actual working model can be manufactured.
There are several advantages to making a prototype circuit board: once the prototype is manufactured and tested, there are few obstacles in the actual PCB manufacturing process.
Through prototypes, customers can clearly understand how their end product will work.
Risks and weaknesses (if any) can be easily identified in the early days.
Once the product is put into production, making changes to the product becomes very expensive and time consuming;
Especially when it comes to mass production.
Typically, production will not start until the prototype board is approved by the customer.
More information on the PCB Prototyping Service there are several different types of PCB that can be prototyped before going into production.
Including single or multiple
Laminated PCB, flexible or rigid PCB, PCB with IMS insulated metal substrate and PF Rogers PCB.
A prototype can also be made for a flexible printing circuit (FPCs)
This is used in several different applications.
There are different types of fpc such as single
Double sided FPC, double contact FPC, double
Dual-sided flexible circuit board, multi-layer FPC.
Most PCB manufacturers offer prototyping services. .
They may provide customers with several packages they can choose from.
Several manufacturers have also added-
Services such as electrical testing and standard tools are provided free of charge.
Since these free services provide added value, these companies should be the first choice.
It usually takes a few days to make a prototype circuit board.
Experts recommend choosing a company specializing in PCB manufacturing, which has a good track record in the field.
Before completing the prototype project, ask the company to provide some samples or references of their previous project.
To get better results, many companies also offer services to improve your existing prototype board.
